T-MAX EW9500 2.2 Tonne Electric Winch

T-MAX EW9500 2.2 Tonne Electric Winch

T-MAX EW9500 2.2 Tonne 12V or 24V DC Electric Winch. 2250kg (22.06kN) Line Pull. Conforming to BS EN14492-1 regulations Power Driven Winches. TYPICAL USES: Light Duty Car Transporters, Plant Moving Vehicles with GVW up to 3500kg, Spec-Lifts, 4×4’s. The T-MAX EW9500 2.2 tonne 12V or 24V DC electric low profile planetary winch has been developed for light industrial use. It incorporates a large electric motor, ensuring good service life. This unit comes supplied with the winch, roller guide and a warderlead control.

Features include

• BS EN14492-1 compliant
• Torque load Limiter Supplied as standard
• 3 stage planetary gearing Providing high mechanical efficiency
• Sealed Heavy Duty Solenoid
• Powerful series wound, high torque motor options 12V or 24V
• Power in I power out Fine control ensures load will not overrun
• Automatic failsafe brake
• Freespool clutch lever Easy to operate lever disengages drum
• 4 way roller guides
• Secure wire rope anchorage Simple thread and wrap system for safe installation of wire rope

T-MAX EW9500 KIT COMPRISES
Electric Winch, 3. 7m wanderlead, roller guides and 8mm galvanised 1960Nmm2 grade 6×36 core wire rope with safety latch hook. Total kit weight 48kg.

THIS PRODUCT IS CURRENTLY NOT AVAILABLE TO BUY ONLINE.

Please call us on (01953) 889998 for more information, including available discounts.
