T-MAX DC5000 5 Tonne Electric Winch

T-MAX DC5000 5 Tonne Electric Winch

T-MAX DC5000 5 Tonne 24V DC Electric Heavy Duty Winch.

5000kg (49kN) Line Pull.

TYPICAL USES: Plant Moving and Commercial Recovery. Fully compliant with BS EN14492-1 regulations Power Driven Winches.

The T-MAX DC5000 24V DC heavy duty electric winch comes complete with 3.7m wanderlead, roller guides, tension roller, load limiter and 12mm diameter x 30m, with high tensile galvanised wire rope with grade 80 safety latch hook.

Optional extras include; mounting plate; wireless IN-OUT control; circuit isolator switch; heavy duty extension kit for wanderlead, airshift freespool clutch.

Features include

• 4 Stage Heavy Duty Machined Planetary Gearing
  • Providing long life and high mechanical efficiency.
• Series Wound, 24V 7HP High Torque Motor
  • Custom manufactured for extended service life.
• Electronic Load Limiter
  • Supplied as standard.
• Freespool Manual Clutch
  • Can also be operated by air-shift control.
• 12mm Diameter Wire Rope
  • With grade 80 safety hook. A longer drum allows for up to 30m length.
• Secure wire rope anchorage
  • Providing full load holding.
• Tension Roller
  • Spring loaded to aid rope wrapping.
• Heavy Duty Solenoids
  • With silver layer on contacts to reduce heating and extend service life. Pre-wired to accept wireless control, reducing installation time.
• 4 Way Roller Guides
  • The horizontal rollers are wide spaced to extend wire rope life.

THIS PRODUCT IS CURRENTLY NOT AVAILABLE TO BUY ONLINE.

Please call us on (01953) 889998 for more information, including available discounts.
