YOKE Swivel Hoist Ring – Type 203 Metric Thread with Alloy Steel Washer
- Rotates through 360º and pivots 180º, rated at 100% at 90º angle.
- Manufactured from forged alloy steel, quenched and tempered.
- Manufactured and tested in accordance with EN1677-1.
- Load rated parts are 100% magnaflux crack detected.
- Individual forged parts and cap screw are traceable to Test Certification.
- Bolts are Metric Thread (ASME / ANSI B18.3.1M).
- Proof tested to 2.5 times the WLL. on the 4 : 1 factor.
- Fatigue rated to 1.5 times the WLL.
- Design Factor 4 : 1.
- All YOKE Lifting Points meet or exceed all the requirements of ASME B30.26.
- Quick and simple assembly, just a tapped hole is required.
