YOKE Swivel Hoist Ring – Extended Length


Addition Options

Product total

Options total

Grand total

Product Code 8-231-_L Category:
William Hackett Chains

YOKE Swivel Hoist Ring Long Bolt – Type 231 Metric Thread

  • Rotates through 360º and pivots 180º, and simultaneously allows lifting from any direction.
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolts are Metric Thread (ASME / ANSI B18.3.1M).
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • Design Factor 4 : 1.
  • All YOKE Lifting Points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.
