Tiger Subsea Lever Hoist

Tiger Subsea Lever Hoist

Main Features

• Suitable for use in multi-immersion applications
• DNV GL Verification tested according to NORSOK R-002
• Available with slipping clutch overload protection
• Range from 800kg – 20000kg
• Available with forged clevis adaptor components
• Patented Quad Cam Pawl System
• Equipped with our unique intelligent Torsion Brake System
• Certified track record with thousands of hours of empirical evidence of performance
• One piece construction pinion gear
• Proven marine specific friction discs
• Meets and exceeds IMCA DO28 Rev 1 guidance notes for offshore lever hoists
• Light load protection at 2% of the rated capacity
• Lifts, holds and lowers the load at 2% of rated capacity
• No requirement for preload tension to activate the ratchet mechanism
• Adaptable to use both inverted and horizontally
• Brake chamber protection from outside contamination
• High performance premium grease
• Stainless steel fixings and fasteners
• Fully Corrosion protected body and components to ensure reliable long term use
• -40°C to +50°C Operating temperature range
• Adjustable chain end anchorage specifically designed to the contours of the hoist
• Also available with stainless steel load chain or spark resistant hooks
• Available with load bearing swivel hooks to meet relevant standards i.e. AS 1418.2
• Meets or exceeds all international standards
